Replacement power and standby switch for Marshall® guitar amps.

On / Off

Also used as OEM part in reissue Marshall® amplfiiers.

1959
1987

Switch Operation
Latching
Maximum Operating Temperature
+55°C
Minimum Operating Temperature
-20°C
Mechanical Life
10000 (Electrical)Cycles
Standards Met
CSA, NF-VDE, UL, UL Recognized
Brand
Apem
Operating Temperature Range
-20 → +55°C
Contact Current Rating
15 A
Actuator Length
17.5mm
Panel Cut Out Size
12.2 (Dia.)mm
Actuator Material
Nickel Plated Brass
Mounting Type
Panel Mount
Contact Configuration
DPDT
Voltage Rating
400V ac
Contact Material
Nickel Alloy, Silver
Terminal Type
Solder
Contact Resistance
10mΩ
Brand: Apem
Panel Cut Out Diameter
12.2mm
